• UAV engine
  • RC Engine
  • Exhaust  amount

    232cc

    Power

    22HP

    Idle  speed

    2000rpm

    Pulling  Force

    45KG/  altitude 50m

    Exhaust  bore/stroke

    46mm*35mm

    compression  Ratio

    7.8:1

    Propeller/max  fuel consumption

    32*10  / 10.2L/h

    Spark  plug

    Irdium

    Weight  of electrical system

    motor870.5g,                      power  manger603g

    Starting  Power Source

    24~45V,6S  /7S lipo battery


    Weight  of main engine and parts

    engine5968gmuffler:  262*2gstand  off22*4gignition:232g

    Weight  of EFI system

    ECU;  182 g,   pump273g

    recommended  propeller

    32*10,34*10

    lubrication  Ratio

    25:1~30:1trail  run

    40:1~50:1normal  flying

    Fuel/lubriction  oil

    92#93#gasoline        2T  fully sythentic oil

    Alternator  output

    24V/28V

    400W

    Auto-Starting  Function

    yes

    Advantage  of EFI System

    EFI  engine  with   many  good  performance characteristics, high power,  oil - saving, low noise, not easy to extinguish, only  once ignition .ECU  can automatically adjust the ignition time,  fuel injection volume and idle  control  according to engine temperature and altitude

    Notes

    In  order to  make  the engine  performance  to the best.  The fuel  pulse width must  be  calibrated on the special test benchaccording  to the corresponding propeller size.  Please  contact  with us before purchase.



  • Exhaust amount

    64cc

    Output

    7HP

    Cylinder Bore/ Stroke

    37MM/30MM

    speed range

    1600-7000 RPM

    Pulling force

    16KG/1000 Meter altitude

    Cylinder arrangement

    twin in line

    Fuel

    Gasoline + 2T synthetic oil

    Lubrication Ratio

    25:1~30: 1(trial run)
    40: 1~50:1(normal flying)   92# 93# gasoline  2T synthetic oil

    Compression Ratio

    7.6:1

    Propeller Recommended

    22*10,23*8  23*10 , 22*10 recommended

    Spark Plug

    DLA CM6,Iridium

    Voltage

    6.6v-8.4v,  2 LiPo batteries  recommended.

    Weight

    Main engine: 2200g Exhaust pipe: 129  Ignition: 133*2g    standoffs: 27*4g

    Customization

    According to Customer’s  need and specifications

    Others



Statement:This engine only used for civilian, like aerial photography, aerial survey, forest patrol inspection, disaster rescue and so on. It is strictly prohibited to attack or destroy. Otherwise, all losses, consequences and legal liabilities arising shall be borne by the user, have nothing to do with our company!

PRODUCT DISPLAY

UAV (Unmanned Aerial Vehicle) engines.

LATEST AND BEST ENGINE
Shandong Feiao Aircraft Engine Co., Ltd specializes in research and development, manufacturing of UAV (Unmanned Aerial Vehicle) engines.

Shandong Feiao Aircraft Engine Co., Ltd specializes in research and development, manufacturing of UAV (Unmanned Aerial Vehicle) engines. With more than 60 employees, our Company engaged in development, manufacturing of UAV engine for about 15 years, we achieved initial success in 2015 and developed new program of small aero-engine in 2016, which made a great leap in Product quality and obtained 9 patents, so we established a new research and development base in Rizhao City, Shandong province, China in 2017, named Shandong Feiao Aircraft Engine Co., Ltd.

All types of engines are all independently designed, researched, and developed by our professional technical team, and our Company also is the first domestic plant to grasp independent technology from material processing treatment, parts thermal processing treatment to whole assembly and testing. And we also accept the customized business from client’s special engine specifications and different needs to provide professional customized engine business.


80 percents of our Products were sold to UAV manufacturers in Civilian fields. Engines were also exported to many overseas markets, like USA, Germany, Brazil, South Africa..., and got good reputations in the world. Our twin-cylinder wind-cooling engine had good performance in Chinese Antarctic Expedition for more than one year and completed expedition task successfully. In 2015, our engine was used in the Germany Flying Games and ranked top there.
