Exhaust amount | 58cc |
Output | 6.0HP |
Cylinder Bore/ Stroke | 46MM/35MM |
speed range | 1600-6700 RPM |
Pulling force | 14.5KG/1000 Meter altitude |
Cylinder arrangement | Single |
Fuel | Gasoline + 2T synthetic oil |
Lubrication Ratio | 25:1~30: 1(trial run) |
Compression Ratio | 8:1 |
Propeller Recommended | 22*10，23*10 23*8 24*8 |
Spark Plug | DLA CM6，Iridium |
Voltage | 6.6v-8.4v, 2 LiPo batteries recommended. |
Weight | Main engine: 1400g Exhaust pipe: 127g Ignition: 133g standoffs: 32*4g |
Customization | According to Customer’s need and specifications |
Others |
This engine is mainly used for fixed-wing with take-off weights (including Gasoline) not more than 10 KGS. Its crankcase, crankshaft, central screws are all made of domestic high-performance materials by CNC processing method. With beautiful appearance, high-precision, drop resistance, fatigue resistance, good stability, strong power performance, we get good reputations from plane enthusiasts after more than 4 years continuously upgrade. Our company will be grateful for your valuable guidance and advice!!
